MODEL |
---|
RAZE CARBON RR |
FRAME |
---|
Raze 29 Stealth Air full Carbon, Zero Suspension System, 130mm travel, Forward Geometry, Carbon Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, HHG internal cable routing, Enduro MAX sealed bearings, shock mudguard, ISCG 05, custom frame protectors. Optional MIND System (EU only) |
SIZES |
---|
S: 380mm / M: 420mm / L: 450mm / XL: 500mm |
REAR SHOCK |
---|
Fox Float DPS Factory Kashima EVOL LV, 205x57.5mm. Settings: Compression 3 positions lever, low-speed compression, low-speed rebound, air preload. Trunnion top mount, 30x8mm bottom bushings |
SHOCK SETTINGS |
---|
Light compression, light rebound, air volume spacer 0.6 |
FORK |
---|
Fox 36 29 Float GRIP2 Factory Kashima, 150mm, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: high and low-speed compression, high and low-speed rebound, air preload |
FORK REMOTE |
---|
|
HEADSET |
---|
Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing |
STEM |
---|
Onoff Krypton FG 30mm, CNC, 31.8mm barbore |
HANDLEBAR |
---|
Onoff Krypton Carbon 1.0, rise: 25mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore |
GRIPS |
---|
Onoff Desert, 1lock-on, 135mmOnoff Krypton FG 30mm, CNC, 31.8mm barbore |
SEATPOST |
---|
Fox Transfer Factory Kashima internal, diameter 31.6mm, S size: 363.5x125mm, M size: 418.3x150mm, L/XL size: 475.1x175mm |
SADDLE |
---|
Fizik Antares R7Onoff Krypton FG 30mm, CNC, 31.8mm barbore |
FRONT BRAKE |
---|
Sram G2 RS, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads |
REAR BRAKE |
---|
Sram G2 RS, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic padsOnoff Krypton FG 30mm, CNC, 31.8mm barbore |
BRAKE LEVER |
---|
Sram G2 RS, SwingLink, tool-free reach adjust |
RIMS |
---|
Mavic CrossMax XL S, 29 Boost 30mm internal width, hookless, tubeless ready, 24 spokesOnoff Krypton FG 30mm, CNC, 31.8mm barbore |
SPOKES |
---|
24 straight-pull double butted spokes |
FRONT HUB |
---|
Infinity hub, Boost 15x110mm, IS 6 boltsOnoff Krypton FG 30mm, CNC, 31.8mm barbore |
REAR HUB |
---|
Infinity hub, ID360 freewheel technology, Boost 12x148mm, IS 6 bolts |
FRONT TYRE |
---|
Maxxis Dissector 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding beadOnoff Krypton FG 30mm, CNC, 31.8mm barbore |
REAR TYRE |
---|
Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead |
CRANKSET |
---|
Sram X1 Carbon Eagle, Boost, DUB axle, Direct mount chain ring, S/M size: 170mm, L/XL size: 175mmOnoff Krypton FG 30mm, CNC, 31.8mm barbore |
CHAINRING |
---|
32T, CNC-machined alloy, X-SYNC 2 |
BOTTOM BRACKET |
---|
Sram DUB BSA, sealed bearings, 73mmOnoff Krypton FG 30mm, CNC, 31.8mm barbore |
PEDALS |
---|
|
CHAIN |
---|
Sram GX Eagle, 12s, PowerlockOnoff Krypton FG 30mm, CNC, 31.8mm barbore |
