FRAME
Series 4 6061 Aluminum Frame, 29” Wheels, 150mm Travel MultiTrac Suspension Platform, Internal Dropper Post and Rear Derailleur Routing, Chainstay Mounted Post Mount Disc Brake, 148x12mm Boost Thru- Axle, 73mm Threaded BB w/ ISCG05 Tabs
FRONT SUSPENSION
RockShox Yari RC, 29”, 160mm of Travel, Air Sprung, Debonair, Compression and Rebound Adjustment, Fast Black Stanchions, 110x15mm Maxle Stealth, 42mm Offset
REAR SUSPENSION
Rock Shox Deluxe Select + RT, Debonair Air Spring, 2 Position Compression and Rebound Adjustment, 205x65mm, Trunnion Upper Mount, 25mmxM8 Lower Mount
RIMS
Marin, Double Wall Alloy, 29mm Inner, Pinned Joint, Disc Specific, 32H, Tubeless Compatible
HUB, REAR
Shimano HB-MT410B, 148x12mm, Centerlock, Microspline Freehub Body
HUB, FRONT
Shimano HF-MT410B, 110x15mm, Centerlock
SPOKE, NIPPLES
14g Black Stainless Steel
TIRES
Vee Tire Flow Snap, 29x2.6”, Top 40 Compound, Enduro Core, 72 TPI, Tubeless Compatible
DERAILLEUR, REAR
Shimano Deore, 12-Speed, SGS
DERAILLEUR, FRONT
-
SHIFT LEVER
Shimano Deore, 12-Speed, SL-6100-IR
CRANKSET
FSA Comet Heavy Duty, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Boost Spacing
BOTTOM BRACKET
Mego EXO 73mm BSA
CHAIN
KMC X-12 Silver and Black
CASSETTE
Shimano, Deore M6100 12-Speed, 10-51T
BRAKE, FRONT
Shimano BR-MT420, 4-Piston Hydraulic Disc Brake, 203mm Rotor
BRAKE, REAR
Shimano BR-MT420, 4-Piston Hydraulic Disc Brake, 180mm Rotor
BRAKE LEVERS
Shimano BL-M4100, I-Spec EV Compatible
HANDLEBAR
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
STEM
Marin 3D Forged Alloy, 35mm
GRIPS
Marin Single Clamp Locking
HEADSET
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
SEATPOST
TranzX, YSP23JL, 1x Remote, Size S 125mm Travel, Size M and L 150mm Travel, Size XL 175mm Travel, 30.9mm
SADDLE
Marin Speed Concept
PEDALS
-
EXTRAS
Bolt-On Thru-Axle
Downtube Protector
